MV-600E/NC HYDRAULIC PRESS: CUSTOM-BUILT FOR THE MILITARY SECTOR

We present the MV-600E/NC four-column hydraulic press, specially designed for deep drawing and stamping tasks in the military sector. This press stands out for its robustness, 600-ton power, and complete customization to meet our client's most demanding requirements. Key Features: SIEMENS SIMATIC S7 1200 PLC and 7” HMI touchscreen to program power, cylinder stroke, speeds, and store up to 300…
admin
22 de October de 2024
Special manufacturing

HIDROGARNE “C” FRAME HYDRAULIC PRESS  Model CD 50E

Specifically designed to perform work involving deep-drawing, stamping, die-cutting, forming, etc. It works with hydraulic pressure lower than 320 bar to ensure the greater durability of the whole hydraulic system. Consist of an electro welded structure made solely of S355JR steel. They are stabilised and mechanized at the end of the structural welding process to ensure perfect parallelism and precision.…
admin
22 de October de 2024
Special manufacturing

HYDRAULIC PRESS CM-50E/NC WITH COLLABORATIVE ROBOTICS UR10E

Perfect combination of technology and flexibility with our special hydraulic press CM-50E/NC adapted to our customer's needs with collaborative robotics UR10E. This press, equipped with the SIEMENS KTP-700, offers precise stroke, pressure and speed adjustments: Approach speed: 42.5 mm/sec Working speed: 9 mm/sec Return speed: 57 mm/sec Piston stroke: 350 mm. A versatile cobot with a payload of 12.5 kg…
admin
22 de October de 2024
Hidrogarne

H-TYPE ECCENTRIC PRESS WITH DOUBLE ROD AND FIXED STROKE

The mechanical press HIDROGARNE mod. PMF 2/300 has a fixed stroke and has a power of 300 tons, it consists of an electro-welded, temperature-stabilized monoblock frame. Equipped with a slide with 8 prismatic guides and double reduction with double connecting rod. FEATURES: H-type monobloc body. Slide-carriage with 8 guides. 2 connecting rods. OMPI pneumatic clutch. Bimanual push button. Three modes…
Pablo LAB242
20 de December de 2022
Hidrogarne

NEW FOLDING HELPER MOD. BP-500

Portable helper compatible with any press brake without connection to the CNC. This folding helper kit is portable. The upper platform can be tilted up to 55º to go with the sheets during the folding process. Electric operation only, does not interfere with the CNC or with the stop of the folder.
Pablo LAB242
22 de March de 2022
Events

HIDROGARNE AT THE 31st BIEMH, INTERNATIONAL MACHINE-TOOL EXHIBITION IN BILBAO -SPAIN-, FROM 13th TO 17TH JUNE 2022

From 13 to 17 June, the 31st edition of the BIEMH, Spanish Machine Tool Biennial, will be held in Bilbao. Once again, we will be present to show you our latest developments in hydraulic presses, mechanical presses and servo-hydraulics press brakes (eco-friendly press brakes with 60% energy savings). We invite you to visit our stand which is in the Hall…
Pablo LAB242
24 de February de 2022
HidrogarneSpecial manufacturing

SPECIAL MANUFACTURING OF MOTORIZED HYDRAULIC PRESS WITH SLIDING FRAME AND MOVEABLE HEADSTOCK WITH A TABLE OF 10 METERS LONG – TL-100/10000-E model

The motorized hydraulic press with sliding frame and moveable headstock HIDROGARNE TL-400/6000-E TL-100/10000-E model is especially designed for the straightening of large volume electro welded structures and flame cut sheets. As all our T-series hydraulic presses, its structure is stabilised and machined at the end of the structural welding process to ensure perfect parallelism and precision. STRUCTURE AND TABLES Electro welded structure made…
HIDROGARNE
10 de September de 2020
HidrogarneSpecial manufacturing

CUSTOM MANUFACTURE OF A HYDRAULIC PRESS WITH 4 COLUMNS

HIDROGARNE hydraulic press mod. MV-800 E with four columns with a power of 800 Tn. Specially designed for drawing and cutting work. STRUCTURES AND TABLES It consists of three electrowelded blocks made exclusively of S355JR steel. It is stabilized and mechanized at the end of the welding process to guarantee perfect parallelism and precision. Calculated and designed with finite element…
HIDROGARNE
15 de May de 2020
